Stud length number 4 is to be used with a total thickness T = 3,05mm to 3,80mm.
The total thickness of your application depends on the style of receptacle you are using. Please check the drawing below to see how you can determine the total thickness of your application. If you do not know which length number you require, please go to our information page about Camloc 2600 series. There you can determine all partnumbers you need for your application.
cross recess pan head
Camloc V26S02-4AGV : steel zinc plated
Camloc 26S8-4D : steel zinc plated
Camloc 26S39-4 : steel nickel plated
Camloc 26S8-4 : steel cadmium plated
Camloc 26S51-4 : stainless steel
Turnlock MTHTLC-4Z : steel zinc plated
Turnlock MTHTLC-4N : steel nickel plated
Turnlock MTHTLC-4S : stainless steel
Monadnock / Lisi 1126004-4 : steel cadmium plated
Monadnock / Lisi 1126008-4 : stainless steel
slotted recess pan head
Camloc V26S01-4AGV : steel zinc plated
Camloc 2600-4D : steel zinc plated
Camloc 26S42-4 : steel nickel plated
Camloc 2600-4 : steel cadmium plated
Camloc 26S38-4 : steel chrome plated
Camloc 2600-4S : stainless steel
Turnlock MTHTLS-4Z : steel zinc plated
Turnlock MTHTLS-4N : steel nickel plated
Turnlock MTHTLS-4C : steel chrome plated
Turnlock MTHTLS-4S : stainless steel
Monadnock / Lisi 1126000-4 : steel cadmium plated
Monadnock / Lisi 1126007-4 : stainless steel
Camloc V26S02-4AGV drawing
