Hi-Temp K-nut M10x1,50 (6 point)

The high temp M10 x 1.50 k-nut is an elliptical deformed self locking nut for high temperature applications. This nut is typically used in motorsports and aerospace applications.

M10x1.5 hi-temp K-nut hexagonal A286 + silver plating

partnumber

KHX-M10-150-XHT

  • Nominal diameter: M10
  • Pitch: 1,50 mm
  • Tolerance: 4H-5H
  • Spanner size: 12 mm
  • Weight per 100pcs: 0,48 kg
  • Material: 1.4944.4 – A286 CRES
  • Hardness: min. 28 HRC
  • Class: 1100 MPa tensile strength
  • Max temperature: 650 °C = 1200 °F
  • Surface: Silver plating

Go to our downloads section to get our most recent catalogues.
In these catalogues you will find all the spec sheets with dimensions and drawings.
